ENGINE
Type Robin, Air cooled, 4-cycle, OHV/OHC, 5 HP, single cylinder
Displacement 169 cc
Power (BHP @ RPM) 6.5 @ 4000
Torque (FT-LBS. @ RPM) 8.3 @ 2800
Starting System Recoil
Carburetion Float with prime
Air filtration Pleated paper cartridge
Ignition Electronic
Lubrication Splash
Exhaust System Aluminized muffler with heat shield
Oil Capacity 1.3 pints
Spark Plugs Champion RL86C
NGK BR6HS
Fuel Capacity .66 gallons
TRANSMISSION
Type-Centrifugal clutch Single ratio
Chain size-3/8" pitch NC 35
AXLES
Rear 1" Hardened alloy steel
TIRES AND WHEELS
Low pressure knobby, 6" steel rim 145/70 x 6"
|
|
FRAME
Type-heavy gauge, jig welded 1" HREW Steel
Finish Baked powder coat
BRAKE
Type-foot operated 4" drum with parking brake
PERFORMANCE
Max speed, approx. 22-24 MPH
Fuel consumption 30-50 MPG
Terrain Flat to gently sloped
SPECIAL FEATURES
Seat Dual seat with adjustable slide
Restraint system Three-point shoulder/lap belts
Engine stop switch In steering wheel
Brush bars 1" HREW Steel
Lights Dual running lights
Safety Whip flag
DIMENSIONS
Curb weight 246 lbs.
Maximum rider weight 250 lbs.
Gross vehicle weight 496 lbs.
Vehicle-overall 61.25"L x 40.25"W x 48"H
Seat to pedals 33.5"-37" |
