ENGINE Tecumseh Robin
Type Tecumseh overhead valve 4 cycle, 5 HP Air cooled, 4-cycle, OHV/OHC, 5 HP
Displacement 172 cc (10.5 cu in) 126 cc
Power (BHP @ RPM) 5.0 @3600 5.0 @3600
Torque (FT-LBS. @ RPM) 7.4 @3200 7.4 @3200
Starting System Recoil Recoil
Carburetion Float with prime Float with prime
Air filtration Pleated paper cartridge Pleated paper cartridge
Ignition Electronic Electronic
Lubrication Splash Splash
Exhaust System Aluminized muffler with heat shield Aluminized muffler with heat shield
Oil Capacity 1.3 pints
Spark Plugs Champion RL86C
NGK BR6HS
Fuel Capacity 3 quarts .66 gallons
TRANSMISSION
Type-Centrifugal clutch Single ratio
Drive ratio-overall 6.6:1
Chain size-3/8" pitch NC 35
AXLES
Rear-stub 1-1/8" 11ga HREW Steel tube
Front 1" 11ga HREW Steel tube
|
|
TIRES AND WHEELS
Front-low pressure knobby, 6" steel rim 145/70 x 6"
Rear-low pressure knobby, 6" steel rim 145/70 x 6"
FRAME
Type-heavy gauge, jig welded 1" 11ga HREW Steel tube
Finish Baked epoxy, powder coated, gloss red
BRAKE
Type-foot operated 4" drum with band
PERFORMANCE
Speed, approx. 22-24 MPH
Fuel consumption, approx. 30-50 MPG
SPECIAL FEATURES
Seat Polyurethane foam with slide adjustment
Restraint system-meets FMVSS 209 and 302 Three-point shoulder/lap belts
Engine stop switch In steering wheel
Custom bars Full brush bars
Other Whip flag
DIMENSIONS
Curb weight 195 lbs.
Maximum rider weight 300 lbs.
Gross vehicle weight 495 lbs.
Vehicle-overall 70"L x 36"W x 49"H
Seat to pedals-adjustable 34"-38"
|
