Recommended ages 12+ yrs.
Engine
Type Air cooled, 2 cycle, single cylinder
Displacement 90cc
Power (BHP @ RPM) 7.0 @ 7000
Torque (Ft-lbs @ RPM) 5.2 @ 7000
Starting System Electric w/key and brake interlock
Fuel Capacity 1.25 gallons
Oil Capacity 1.5 quarts
Spark Plug NGK BP7HS or Champion L82YC
Transmission
Type Automatic (C.V.T., V-Belt)
Chain Size 1/2" Pitch . . . NC420
Tires & Wheels
Front 20 x 7 x 8 Low Pressure Knobby, Steel Rim
Rear 18 x 9.5 x 8 Knobby, Low Pressure Knobby, Steel Rim
Frame
Type - heavy gauge - jig welded 1" 11 ga HREW
Finish Baked Powder Coat Gloss, Black
Suspension
Front - independent Oil damped, single A-arm (3")
Rear - semi-independent Oil damped, single swing shock (4")
|
|
Brake
Front - Hand Operated Double drum
Rear - Hand Operated Single drum
Parking - Hand Operated Rear push button
Performance
Maximum Speed (Approx) 15-30 mph
Fuel Consumption (Approx) 20-30 mpg
Terrain Hills and slopes, grass, dirt, mud, sand
Special Features
Seat High Density Foam
Polypropylene Body with full fenders Red
Engine Stop Switch Left handlebar
Other Mud guards, foot/toe guards, flag
Dimensions
Curb Weight 284 lbs.
Maximum Rider Weigth 200 lbs.
Gross Vehicle Weight 454 lbs.
Vehicle: Overall Length 60"
Width 35"
Height 36.5"
Seat height 27.5"
Safety Statement
Manco ATVs comply with all standards for safety and performance per ANSI/SVIA-2001.
|
